KEY FEATURES

Quality

Quality

Designed with extreme care in the integration of each individual component, it ensures accuracy, repeatability and reliability

Productivity

Productivity

Measures with extreme speed any type of surfaces, without any need of markers and of surface preparation to reduce the set-up time

Efficiency

Efficiency

The offline simulation for automation and ispection makes the system always available for measurements

Flexibility and Mobility

Flexibility

QBOX is a system that can be adapted to the different measurement needs, various part sizes and geometries. Load and unload is easy and can be automated (optional)

Custom made

Custom made

Following optional packages: Visual pack, Safety pack, Comfort pack, Offline programming, Easy Load pack.

PROCESS CONTROL

PROCESS CONTROL

QBOX is designed to be integrated with the most advanced software for Statistical Process Control

Quality

Quality

Designed with extreme care in the integration of each individual component, it ensures accuracy, repeatability and reliability

Productivity

Productivity

Measures with extreme speed any type of surfaces, without any need of markers and of surface preparation to reduce the set-up time

Efficiency

Efficiency

The offline simulation for automation and ispection makes the system always available for measurements

Flexibility and Mobility

Flexibility

QBOX is a system that can be adapted to the different measurement needs, various part sizes and geometries. Load and unload is easy and can be automated (optional)

Custom made

Custom made

Following optional packages: Visual pack, Safety pack, Comfort pack, Offline programming, Easy Load pack.

PROCESS CONTROL

PROCESS CONTROL

QBOX is designed to be integrated with the most advanced software for Statistical Process Control

Application Fields

Manufacturing Area

The high flexibility of the system combined with the simple and easy use, makes QBOX suitable for multiple applications. QBOX integrates the most advanced technologies available on the market and provides excellent performance , high quality standards and maximum reliability.

Products

QBox MiniCobot

QBOX
MiniCobot

COLLABORATIVE ROBOT + COMET L3D

QBox Cobot

QBOX
Cobot

COLLABORATIVE ROBOT + COMET L3D

QBox Compact

QBOX
Compact

STANDARD ROBOT + COMET L3D

QBox Power

QBOX
Power

STANDARD ROBOTS + TSCAN CS +

QBox Evolution

QBOX
Evolution

STRD + TSCAN CS +

Qbox MiniCobot
Qbox MiniCobot

Ultra compact, versatile and collaborative solution. QBOX MiniCobot is suitable for small to medium-sized objects measurements, it can be embedded in a work environment where the operator can remain in contact with the device.

Characteristics of the
component to be measured

Superficie

Surface

Any kind of collaborative surface, without using white developer spray or marker. For highly shiny or black surfaces the use of the white developer spray is necessary.

Peso

Weight

Up to 100 kg

Dimensione

Size

Up to 1000 mm.

Materials

Technical data

Dimensions (WxLxH) 1.6m x 0.8m x 2.2m.
Measurement technology Blue Led light.
Inspection software Included in the basic supply, the package can be chosen among different typologies. Fully integrated programming of offline measurement cycles and inspection.
Simulation software Included in the basic supply. Integrated simulation environment for quick and easy programming with self-learning process.
Power supply Three-phase with neutral, 230V, 50Hz, 16A
Automation 6-axis control anthropomorphic robot. On request additional axis
Qbox MiniCobot
Qbox Cobot
Qbox Cobot

Compact, versatile and collaborative solution. QBOX Cobot is suitable for medium-sized objects measurements, it can be embedded in an industrial environment, where the measurement area has to be isolated from the rest of the process, while maintaining the advantages of a collaborative technology.

Characteristics of the
component to be measured

Superficie

Surface

Any kind of collaborative surface, without using white developer spray or marker. For highly shiny or black surfaces the use of the white developer spray is necessary.

Peso

Weight

Up to 100 kg

Dimensione

Size

Up to 1000 mm.

Materials

Technical data

Dimensions (WxLxH) 2.11m x 2.81m x 2.62m.
Measurement technology Blue Led light.
Inspection software Included in the basic supply, the package can be chosen among different typologies. Fully integrated programming of offline measurement cycles and inspection.
Simulation software Included in the basic supply. Integrated simulation environment for quick and easy programming with self-learning process.
Power supply Three-phase with neutral, 230V, 50Hz, 16A.
Automation 6-axis control anthropomorphic robot. On request additional axis
Qbox Cobot
Qbox Compact
Qbox Compact

Industrial solution, equipped with a box, with a traditional robot. Ideal for medium to large components. Equipped with a sliding door to completely isolate the measuring cell from the surrounding environment, it can be embedded in almost all productive industrial contexts.

Characteristics of the
component to be measured

Superficie

Surface

Any kind of collaborative surface, without using white developer spray or marker. For highly shiny or black surfaces the use of the white developer spray is necessary.

Peso

Weight

Up to 1000 kg

Dimensione

Size

Up to 1400 mm.

Materials

Technical data

Dimensions (WxLxH) 2.68m x 2.28m x 2.64m.
Measurement technology Blue Led light.
Inspection software Included in the basic supply, the package can be chosen among different typologies. Fully integrated programming of offline measurement cycles and inspection.
Simulation software Included in the basic supply, the package can be chosen among different typologies. Fully integrated programming of offline measurement cycles and inspection.
Power supply Three-phase with neutral, 400V, 50Hz, 32A.
Automation 6-axis control anthropomorphic robot. On request additional axis
Qbox Compact
Qbox Power
Qbox Power

Industrial solution, equipped with a box, with a traditional robot and laser sensor. Ideal for medium and large components. Equipped with a sliding door to isolate the measuring cell completely from the surrounding environment, it can be embedded in almost all industrial production environments. The Laser sensor carries all the advantages of this acquisition technology.

Characteristics of the
component to be measured

Superficie

Surface

Any kind of surface, also non-collaborative without using white developer spray or marker.

Peso

Weight

Up to 1500 kg

Dimensione

Size

Up to 2000 mm without using markers.

Materials

Technical data

Dimensions (WxLxH) 4.7m x 4.7m x 2.6m.
Measurement technology Laser-optical.
Inspection software Included in the basic supply, the package can be chosen among different typologies. Fully integrated programming of offline measurement cycles and inspection.
Simulation software Included in the basic supply. Integrated environment simulator for virtual programming.
Power supply Three-phase with neutral, 400V, 50Hz, 32A.
Automation 6-axis control anthropomorphic robot. On request additional axis.
Qbox Power
Qbox Evolution
Qbox Evolution

Industrial solution, designed and built according to specific customer needs. Ideal for components of any size. All the elements are integrated into an unique measurement environment, whose purpose is to be fully integrated with the production process. Automatic loading and unloading devices are provided, that can be performed at the same time of the measurement operations, integrated support systems for the component to be measured and automatic closing system, to make the whole system a "one click" application.

Characteristics of the
component to be measured

Superficie

Surface

Any kind of surface, also non-collaborative without using white developer spray or marker.

Peso

Weight

Depending on the components to be measured.

Dimensione

Size

Depending on the components to be measured.

Materials

Technical data

Dimensions (WxLxH) Depending on the needs.
Measurement technology Laser-optical.
Inspection software Included in the basic supply, the package can be chosen among different typologies. Fully integrated programming of offline measurement cycles and inspection.
Simulation software Included in the basic supply. Integrated environment simulator for virtual programming.
Power supply Three-phase with neutral, 400V, 50Hz, 32A.
Automation 6-axis control anthropomorphic robot. On request additional axis.

QBox Power configuration example

T- Scan pistola e tracker Robò + tavola rotante + Controller Support Plate Parts Air Conditioner Control room Box Control room monitor Roof opening

T- Scan CS+

Laser scanning device
High digitizing speed
No Spray
No Markers

T- Track CS+

Optical Tracker
Wide measurement volume 6.3m^3

Controller Rack Unit

Centralized control and management of all connected devices
Controlled temperature

Anthropomorphic robot

With 6 degrees of freedom for a complete measuring volume to capture the entire part

Auxiliary axis

Rotary table for automated object positioning

Dedicated software to ensure the complete safety of the operators and to avoid any kind of collision

High measurement accuracy by opticaltracking unit, independent by robot accuracy

Adaption to almost every common robot type/manufacturer

The thread grid plate allows to fix all the supports for the part that has to be measured, in a very easy and fast way.

Support plate

Steel support plate with threaded holes

Up to 1700 x 1500 mm

Support Plate Size

Up to 1200 kg

With dedicated support plate

Parts

No parts preparation, no spray, no markers, simple support

Parts

Plastic, sheet metal, foundry, composite and many other materials can be measured without any spray or markers


Parts

Measurement of varying type of surfaces in one scan path without time consuming preparation

Air conditioner

If necessary for your ambient, air conditioner can be installed

Air conditioner

Temperature of the Scanning area can be controlled by the air conditioner installed inside the box

Windows

To follow the whole measurement process in a safe zone

Door

External access to the Control room

Integrated office inside QBOX with PC and monitors, in order to create an isolated area to perform the programming tasks for the measurement and control cycles and to check the results

Insulating panels

Control units

Easy access for maintenance

Access panel

To guarantee the safety requirements and protect the measuring environment from the external ambient.

2.65m

Height

4.70m

Depth

4.70m

Width

Ambient light

Led stripes provide comfortable measuring area

Control room

For programming and verifying the measurements in a "safe" ambient

Control station

To manage the measuring process

Front monitor

To check the status of the measures also from a distance

50


Inches monitor

2

Monitor on side for QBOX management

1


Front monitor

1

Monitor inside the control room

Sliding door

Frontal entry to the measurement
area of QBOX

Loading

Wide access to the load area, useful for operator, forklift and crane

Roof opening
To facilitate the operations
of crane loading

2000mm

For the Scanning Area



compliant
To satisfy safety requirements
